Airbag (SRS)

Airbag (SRS)


Component location


22A

Fuse, in fuse holder in dashboard

331

Control module, under rear of centre console between front seats

333

Airbag, in steering wheel and/or above glovebox

336

Contact roller, inside steering wheel

429

Resistor, at control module (cars with no passenger airbag)

445

Data link connector, under dashboard on left-hand side

540A

SRS lamp, in main instrument unit (cars with no central warning lamp)

540B

SRS lamp/central warning lamp, in main instrument unit

G4

Grounding point in control module mounting

G33P

Grounding point, data link connector, at bottom of left-hand A pillar

G33S

Grounding point, data link connector, at bottom of left-hand A pillar

H2-52

Two-pin connector on steering column assembly
